ZOOM Livetrak L6max

Big Mixer Energy The LiveTrak L6max is packed with all the features you’d expect from a full-size mixer, plus a multi-track recorder. It’s compact, battery powered, and ready to be the centerpiece of your live show, rehearsal or podcast. Small Enough for a Duo, Big Enough for a Band Whether you are a full-band, an acoustic duo or a solo performer, the L6max is ready. With 4 combo inputs (including 2 with Hi-Z) and 8 line inputs, its 12 channels offer the flexibility you need for any session. Custom Monitoring Options Two headphone outputs with one customizable Sub-Out mix let you monitor exactly what you need, wherever you are on stage. High-Output Ready Channels 5–8 include a -20 dB PAD switch so you can handle loud sources such as vintage synths and Eurorack modules. No attenuator required. OLED Display The high-contrast OLED display helps you create projects and adjust settings with ease. 14 Tracks of Recording Capture up to 12 individual tracks plus a stereo mix directly to SD cards up to 2TB. Projects can be saved and recalled for mixing anytime. Unlimited Overdubbing You can mix and bounce tracks to the dedicated ‘bounce track’’ freeing up additional channels to keep adding layers. If the bounce doesn’t hit the mark, ‘undo’ it and try again. Even after a bounce Individual files are saved to the SD card for future mixing. AI Noise Reduction Turn on AI Noise Reduction and let the L6max intelligently remove hum, hiss, and background noise - while preserving every detail of your voice and instruments. Let’s Get Loud For huge drums and loud guitar solos, the L6max records clip-free audio in 32-bit float. Channels 1-4 have dual AD converters, keeping mic signals pristine across extreme dynamics. 3-Band EQ for Every Channel Dial in the perfect tone with LOW, HIGH, and MID EQ on each channel Onboard Effects Build the perfect mix with onboard effects including Reverb, Delay, and Echo. Use the TAP key to set delay times. Advanced Compressor The master track compressor adds punch and saturation to your mix. With 32-bit float the audio will never clip, even at high volumes. Easily Record with your Smartphone or Computer The L6Max can be used as a 32-bit float 12-in / 4-out USB audio interface for your computer, iOS, or Android device while recording simultaneously to the microSD card. It’s also a control surface for your favorite DAW. Pro-Level Mixer Functions Flexible Routing with AUX Sends Two AUX Sends with pre/post-fader options for FX loops and monitor feeds Scene Memory Store up to four mixes and recall them anytime with a single button Sound Pads with MIDI Sync Trigger jingles, sound effects, or samples on demand. Sound Pads can even sync to a MIDI clock for live electronic performances. MIDI I/O and USB MIDI Connect external synths and grooveboxes or integrate with MIDI apps on your computer and mobile devices. Customize with the L6 Editor App The free L6 Editor app for Mac and Windows lets you customize pads, effects, and MIDI assignments with ease. Stay Powered, Stay Mobile Power the L6max via AA batteries, USB bus power, or a mobile battery pack. Euro Rack Integration The L6max is mountable to a standard Eurorack case using the optional ERL-6 rack ears and power supply. Specifications: Inputs MIC/LINE (mono): 4 inputs LINE (stereo): 4 Outputs AUX SEND (mono): 2 MASTER (stereo): 1 MONITOR (stereo): 1 SUB-OUT (stereo): 1 Connectors (MIC/LINE) 4 × XLR/TRS combo jacks (XLR: 2 HOT, TRS: TIP HOT) Input gain: adjustment unnecessary (dual A/D converter circuits used) Input impedance: XLR ≥ 3.8 kΩ; TRS ≥ 18 kΩ (Hi-Z off) / ≥ 1 MΩ (Hi-Z on) Maximum input level: XLR +4 dBu, TRS +24 dBu Phantom power: +48 V, channel total ≤ 20 mA Line Inputs Connectors: 8 × TS phone jacks Input impedance: ≥ 30 kΩ Maximum input level: +4 dBu (PAD 0 dB), +24 dBu (PAD −20 dB) Aux Send Connectors: 2 × TRS phone jacks (impedance balanced) Maximum output level: +9.5 dBu Output impedance: 147 Ω Master Out Connectors: 2 × TRS phone jacks (balanced) Maximum output level: +15 dBu Output impedance: 147 Ω Monitor / Sub-Out Connector: TRS phone jack Maximum output level: 50 mW + 50 mW (63 Ω load) Output impedance: 14.7 Ω Buses Master: 1 Sub-mix: 1 Aux send: 2 Send EFX: 1 Channel Strip EQ High: 10 kHz, ±15 dB, shelving Mid: 100 Hz – 8 kHz, ±15 dB, peaking Low: 100 Hz, ±15 dB, shelving Level meters: 6 segments Send effects: 6 types Recorder Maximum simultaneous recording tracks: 14 Maximum simultaneous playback tracks: 14 Recording formats: 48 kHz, 32-bit float, mono/stereo WAV Recording media: microSDHC / microSDXC (Class 10 or higher, see Zoom website for compatible cards) Audio Interface Input channels: 14 Output channels: 4 Sampling frequency: 48 kHz Bit depth: 32-bit float / 24-bit Interface: USB 2.0 (High Speed, Mass Storage Class) Frequency response: 20 Hz – 20 kHz (−1.0 dB / +0.5 dB) Equivalent input noise: −120 dBu or less (IHF-A, at 150 Ω input) Display 128 × 64 OLED Power Power consumption: max. 5 W Estimated continuous recording time (14-track recording, phantom power off, headphones used (63 Ω load), no MASTER output): Alkaline: ~1.5 h NiMH (1900 mAh): ~2.5 h Lithium: ~5 h Power supply: 4 × AA batteries (alkaline, lithium, or rechargeable NiMH), AC adapter (ZOOM AD-17: DC 5V/1A), USB bus power supported Dimensions / Weight 284 mm (W) × 114 mm (D) × 46.5 mm (H) Weight (main unit only): 673 g Weight (including batteries): 767 g Note: 0 dBu = 0.775 Vrms
